Product Description:
Non Metal Fabric Compensator can compensate axial, transverse and
angular direction. It has the characteristics of no thrust,
simplified support design, corrosion resistance, high temperature
resistance, muffling and vibration reduction, etc. It is especially
suitable for hot air duct and fume duct.
Advantages:
1.Multidimensional direction can be compensated. Various forms,
large compensation and long service life;
2.Effective compensation or elimination of installation errors;
3.Low stiffness and small elastic reaction;
4.High temperature range and good corrosion resistance;
5.It can effectively isolate vibration and reduce noise.
Technical Parameters:
| Round products types | Dw | D₁ | D₂ | D₃ | b | d | n | Φd |
| mm |
| Φ108 | 108 | 200 | 164 | 110 | 10 | 14 | 4 | 10 |
| Φ159 | 159 | 251 | 215 | 161 | 8 |
| Φ219 | 219 | 311 | 275 | 211 |
| Φ273 | 273 | 365 | 330 | 275 | 12 |
| Φ325 | 325 | 427 | 385 | 327 |
| Φ377 | 377 | 479 | 435 | 379 | 12 |
| Φ426 | 426 | 528 | 490 | 428 |
| Φ480 | 480 | 595 | 540 | 483 | 12 | 18 |
| Φ720 | 530 | 645 | 600 | 533 |
| Φ630 | 630 | 745 | 700 | 633 | 16 |
| Φ720 | 720 | 843 | 800 | 723 |
| Φ820 | 820 | 943 | 900 | 823 | 20 | 14 |
| Φ920 | 920 | 1043 | 1000 | 923 |
| Φ1020 | 1020 | 1153 | 1100 | 1023 | 14 | 22 |
| Φ1120 | 1120 | 1253 | 1200 | 1123 |
| Φ1220 | 1220 | 1353 | 1300 | 1223 |
| Φ1320 | 1320 | 1453 | 1400 | 1323 | 24 |
| Φ1420 | 1420 | 1553 | 1500 | 1423 | 16 | 28 |
| Φ1820 | 1820 | 1963 | 1910 | 1823 | 26 | 16 |
| Φ2020 | 2020 | 2163 | 2110 | 2023 | 32 |
| Φ2220 | 2220 | 2363 | 2310 | 2223 | 18 | 36 |
| Φ2420 | 2420 | 2563 | 2510 | 2423 | 40 |
| Φ2820 | 2820 | 2983 | 2915 | 2823 | 20 | 32 | 44 | 18 |
| Φ3220 | 3220 | 3383 | 3315 | 3223 | 22 | 52 |
| Φ3620 | 3620 | 3783 | 3715 | 3623 | 56 |
| Note:We can make it according to your requirements. |
Applications:
The liwei Non-Metal Fabric Compensator is widely used in various
scenarios such as chemical engineering, construction, water supply,
drainage, petroleum, light and heavy industries, refrigeration,
sanitation, water heating, fire protection, electric power and
other basic projects. It is a versatile product that can be made
into different varieties such as acid, alkali, corrosion, oil, high
temperature, radiation, wear resistance, aging, and other varieties
to adapt to a variety of media and environment.
Support and Services:
Our Non Metal Fabric Compensator product comes with comprehensive
technical support and services to ensure optimal performance and
longevity. Our team of experts is available to provide assistance
with installation, maintenance, troubleshooting and repair. We also
offer training programs and seminars to help customers maximize the
benefits of our product. Our services include:
- On-site technical support
- Remote technical support
- Customized solutions
- Maintenance and repair services
- Training programs and seminars
Packing and Shipping:
The liwei Non-Metal Fabric Compensator is meticulously packaged to ensure its integrity and safety during
transportation. Each joint is individually wrapped in protective
material to guard against scratches and impacts. The wrapped
products are then carefully placed into sturdy, corrugated boxes
that are designed to withstand the rigors of shipping. The boxes
are sealed with heavy-duty packing tape and clearly labeled with
handling instructions and product information to facilitate proper
transportation. Prior to dispatch, all packages are inspected to
ensure they meet our strict packaging standards, guaranteeing that
your product arrives in perfect condition.
FAQ:
Here are the frequently asked questions and answers about the
Non-Metal Fabric Compensator:
Q: What is the brand name of this compensator?
A: The brand name of this compensator is liwei.
Q: What is the model number of this compensator?
A: The model number of this compensator is DN108-DN3620.
Q: Where is this compensator made?
A: This compensator is made in Henan, China.
Q: What is the minimum order quantity for this compensator?
A: The minimum order quantity for this compensator is 1 set.
Q: What is the price of this compensator?
A: The price of this compensator is negotiable.
Q: Can the products be manufactuered by customer's requirement?
A: Yes, the specifications stated above are the standard ones, we
can design and manufacture as requirement.
Q:Can you send samples?
A:Of course , we can send samples to all parts of the world,samples
can be provided for free.
