    EPDM/NBR/NR/FKM Etc. Eccentric Reducing Rubber Joint For Petroleum Industry Support Third-Party Testing

    Ask Lasest Price
    Brand Name : liwei
    Model Number : DN100*DN80-DN500*DN300
    Certification : ISO9001, TUV, WRAS, CO, MTC, PL, IV etc
    Price : Price Negotiable
    Payment Terms : T/T, Western Union, L/C, D/A, MoneyGram
    Supply Ability : 100000 Pieces per Month
    Delivery Time : After payment 15-30 working days
    • Product Details
    • Company Profile

    EPDM/NBR/NR/FKM Etc. Eccentric Reducing Rubber Joint For Petroleum Industry Support Third-Party Testing

    Product Description:

    The eccentric reducing rubber joint mainly consists of a rubber body, a metal flange (usually steel or stainless steel), and possibly a reinforcing layer (such as wire mesh). The design feature is that the rubber body is eccentric shape, and the diameter of one end is larger than that of the other end to adapt to different sizes of pipe connections. At the same time, the rubber body may contain multiple layers of rubber of different hardness to enhance its pressure, corrosion resistance and wear resistance. In addition, metal flanges are used to secure the connection to the piping system, ensuring the tightness and stability of the joint.

    Features:

    Strong adaptability
    Shock absorption and noise reduction
    Good sealing
    Strong corrosion resistance
    High bearing capacity
    Easy to install
    Low maintenance cost

    Technical Parameters:

    Main connecting dimension
    Nominal
    diameter
    Length
    (mm)
    Technical parametersTechnical parameters
    DD₀n-ΦDD₀n-Φ
    100×801802201808-Φ182001608-Φ18
    150×802002852408-Φ222001608-Φ18
    150×1002002852408-Φ222201808-Φ18
    150×1252002802408-Φ222502108-Φ18
    200×1002003402958-Φ222201808-Φ18
    200×1502203402958-Φ222802408-Φ18
    250×10022039535012-Φ222201808-Φ18
    250×12522039535012-Φ222502108-Φ18
    250×15022039535012-Φ222852408-Φ22
    250×20022039535012-φ223402958-Φ22
    300×12528044540012-Φ222502108-Φ18
    300×15022044540012-Φ222852408-Φ18
    300×20018044540012-Φ223402958-Φ22
    300×25022044540012-Φ2239535012-Φ22
    350×12525550546016-Φ222502108-Φ18
    350×20022050546016-Φ223402958-Φ18
    350×30022050546016-Φ2244540012-Φ22
    400×20022056551516-Φ223402958-Φ22
    400×25022056551516-Φ2239535012-Φ22
    400×30022056551516-Φ2244540012-Φ22
    450×20022061556520-Φ263402958-Φ22
    450×25022061556520-Φ2639535012-Φ22
    500×30025567062020-Φ2644540012-Φ22
    • Special size and length can be customized for you.

    Advantages:

    • Highly adjustable:
    The eccentric reducing rubber joint is designed to allow a certain space for fine tuning, which makes the Angle or position adjustment according to actual needs during the pipe connection process to ensure the accuracy and stability of the connection. This flexibility increases the flexibility and efficiency of the installation.
    • Good water resistance:
    The sealing structure of the rubber joint is tight, which can effectively prevent the leakage problem of the pipe connection. In wet or underwater environments, this feature is particularly important to ensure the safe operation of the piping system and the normal transmission of the medium.
    • High and low temperature resistance:
    Some of the specially designed eccentric reducing rubber joints are capable of operating over a wide temperature range, including high and low temperature environments. This makes them suitable for a variety of operating conditions, including piping systems that require high or low temperature resistant media.

    Our Services:

    • Delivery inspection (pressure test, specification test, material, quantity, packing).
    • The quality is guaranteed for 12 months, supportthird-party testing.
    • Free solutions and drawings can be provided.
    • A well-trained and disciplined professional packaging team.
    • 24h online service, quick response before and after sales.
    • Support online factory inspection
    • On-time delivery
    • Free samples can be provided

    Packing and Shipping:

    Product Packaging:

    • The Eccentric Reducing Rubber Joint will be packed in a sturdy cardboard box to ensure safe transport.
    • The product will be wrapped in bubble wrap to prevent any damage during shipping.
    • Each box will contain one Eccentric Reducing Rubber Joint.

    Shipping:

    • Shipping will be handled by our trusted courier partners.
    • Delivery time will depend on the destination and shipping method selected.
    • A tracking number will be provided to the customer once the product has been shipped.

    FAQ:

    Q. What is the brand name of the Eccentric Reducing Rubber Joint product?

    A. The brand name of the product is liwei.

    Q. What is the supply ability of the Eccentric Reducing Rubber Joint product?

    A. The product has a supply ability of 100000 pieces per month.

    Q. What is the delivery time for the Eccentric Reducing Rubber Joint product?

    A. The product will be delivered after payment within 15-30 working days.

    Q. Is the price of the Eccentric Reducing Rubber Joint product negotiable?

    A. Yes, the price of the product is negotiable.

    Q: How can you guarantee the quality or any warranty?

    A: If any quality problems during use, all the products can be returned or according to consumer's requests.

    Q: Can I visit your factory before the order?

    A: Yes, welcome to our factory to check the quality.
